Key upgrades include a dedicated ASIC for cleaner S/PDIF and AES-EBU outputs, improved MEMS clocks for lower jitter, I2S over HDMI connectivity for compatible high-end DACs, and a 12V trigger to power on/off other components.
If you demand the pinnacle of digital transport performance, the Rivo+ is the solution.
The Rivo+ features a dedicated ASIC to generate the S/PDIF and AES-EBU output signals, offloading this crucial task from the CPU. This specialized integrated circuit is designed to produce these digital output signals with uncompromising precision, free from any potential interference or jitter introduced by the main processor.
Powering this dedicated ASIC is a high-quality MEMS (Micro-Electro-Mechanical Systems) clock, which provides an exceptionally stable and low-jitter timing reference. Coupled with low-noise voltage regulators, this enhancement to the RIVO+ ensures the output signals maintain the utmost purity and refinement.
Digital Coaxial S/PDIF
Audio Output, up to PCM 192kHz/24bit and DSD64 via DoP
Digital AES/EBU
Audio Output, up to to PCM 192kHz/24bit and DSD64 via DoP
Digital I2S over HDMI Output
Audio Output, up to PCM 768kHz/32bit and DSD256
USB Output
Audio Output, up to PCM 768kHz/32bit and DSD256 (via USB DAC)
USB DAC Port
1x USB 2.0
USB
1x USB 3.0, 1x USB 2.0
LAN
Gigabit 10/100/1000M
Wireless
Wi-Fi 802.11a/b/g/n/ac, 2X2 MIMO with RSDB
Bluetooth
5.0
Supported Formats
DSD, WAV, FLAC, Alac, Aac, Vorbis, Mp3 and others
UPNP DLNA
Renderer with Open Home support
Supported Services
Airplay via Shairport Sync, Spotify & Spotify Connect, TIDAL & TIDAL Connect, QOBUZ
Available Plugins
Youtube, Squeezelite, Radio Paradise, Podcasts, Pandora, Fusion DSP, Roon Bridge, Soundcloud, Mixcloud
CPU
Amlogic S905D3, Quad Core 1.9 GHz
RAM
2 GB DDR4
Internal Storage
16 GB EMMC
Power Supply
5V, 3A
