EC3 was designed as a compact CD player, fitting perfectly alongside the Shanling EM5 and EA5 Streamers.
Built around well proven Philips CD80 drive mechanism and Sanyo HD850 laser head, as a top-loading CD player with a transparent cover. Offering digital outputs in form of coaxial and optical SPDIF, for easy connection to external DACs or receivers. It also packs its own audio circuit, utilizing ESS ES9219C DAC and LTA8092 op-amp through headphone output or RCA, with the option to serve as a pre-amplifier.
But EC3 is not just a simple CD player with few playback buttons. Shanling have added the Ingenic X2000 platform, a practical 1.6-inch screen and our custom-built system, providing further settings and features directly to the player. Allowing it to act as a Bluetooth DAC or serving as a Hi-Res music player by connecting any USB drive with audio files, with additional control through Eddict Player app.
App Control
For CD and USB Drive Playback.
Download Shanling's Eddict Player app to your Android or iOS device to comfortably control EC3. Acting as a simple playback and volume control for use with CDs. Or switch to USB drive playback and use the app to browse through all the files, artists and albums.
SPECIFICATIONS
General
• Specification
• Dimensions: 25.5 x 18.8 x 6.8 cm (L x W x D)
• Weight: 2.4 kg
• Power Drain: 15W
Headphone Output
• Low Gain Output: 20mW @ 32 Ohm
• High Gain Output: 70mW @ 32 Ohm
• Frequency Response: 20 - 40 khz (+-0.5dB)
• Signal-to-Noise Ratio: 114 dB
• Dynamic Range: 116dB
• Distortion: 0.0015%
• Channel separation: 65dB @ 32 Ohm
• Output Impedance: 0.4 Ohm
RCA Outputs
• Output Level: 2.3V
• Frequency Response: 20 - 40 khz (+-0.5dB)
• Signal-to-Noise Ratio: 116 dB
• Dynamic Range: 116dB
• Distortion: <0.001%
Bluetooth: Bluetooth 5.0 Receiver
Bluetooth Codec Support: LDAC / aptX HD/ aptX / AAC / SBC
