ACOUSTIC ENERGY AE100.2 Bookshelf Loudspeakers

The AE100² is a compact stand-mount/bookshelf loudspeaker exhibiting qualities perfectly embodying those of Acoustic Energy.

The AE100² has been designed with a view to achieving high sound pressure levels from a small enclosure. This is obtained principally through the use of a 130mm mid-bass drive unit built around an ultra-high force, long throw motor system. Bass performance is augmented by a slot shaped duct allowing for a considerable cross-sectional area while negating the issues of air turbulence.

ACOUSTIC ENERGY AE100.2 Bookshelf Loudspeakers

A 25mm soft dome tweeter featuring our Wide Dispersion Technology completes the driver compliment and is housed within a 15mm HDF cabinet. Taking design cues from the award-winning 500 Series and finished in a choice of black, satin white or walnut vinyl veneer finishes. The AE100² is sure to look good placed on speaker stands or bookshelves, while delivering a sound that belies its compact size.

The 3-way crossover is impedance compensated to avoid the resonance issues which would otherwise slow bass delivery and colour mid-range performance. Particular attention has also been paid to the phase and time alignment for optimum integration and soundstage. The result is a loudspeaker offering smooth, wide dispersion high frequencies with a clean mid-range and lightning fast bass response. The inert cabinet enclosure is constructed from 15mm HDF and like it’s smaller AE109² brother, supplied mass loaded to help dampen cabinet vibrations. The internal bracing system has been carefully tuned to reduce cabinet resonances and mid-range colouration, whilst the new AE120² benefits from a subtlety styled, discrete black plinth to aide stability, further improving dynamics and stereo focus.

TWEETER
Acoustic Energy’s bespoke 25mm soft dome tweeter was designed in tandem with the 100 Series bass driver to offer optimum integration and tonal matching. Paired with our Wide Dispersion Technology waveguide, the crossover region between drive units is audibly seamless whilst the high-power neodymium motor assembly ensures reliable, distortion-free high-volume playback.

DRIVERS
The 130mm bass/mid driver used in the 100 Series has been developed with a high power, long excursion motor to provide satisfying volume levels and bass extension from relatively compact enclosures. The doped paper cone enables a higher crossover point for smoother mid-range and seamless crossover with the tweeter, creating extremely high fidelity, detailed and above all musical sound reproduction.

CABINET
The 100 Series uses thin, 15mm high density (HDF) enclosures with carefully tuned bracing, reducing harmful resonances whilst retaining body and substance from compact, practical cabinets. The rear slot porting* enhances smooth bass extension with minimal room impact, allowing easy placement. The AE109² and AE120² feature inert mass-loading for additional stability and acoustic damping, all models come supplied with slim magnetic grilles.

SPECIFICATIONS
Drive Unit: 130mm paper cones
Tweeter: 25mm fabric dome
Frequency Range: 51Hz – 26kHz
Sensitivity: 87dB
Peak SPL: 112dB
Power Handling: 120 Watts
Crossover Frequency: 2.9kHz
Impedance: 6 Ohms
Design: 2 Way
Grilles: Slim, cloth magnetic fit
Dimensions (mm): 290 x 165 x 250 (HxWxD)
Weight: 9.2kg (pair)
Finishes: Satin Black or Walnut Vinyl veneer
